Rubber Anti Vibration Mountings, Generator Rubber Mounts AVM M12 M14 M16 M18 M20
Description:
Anti-Vibration mounts are designed to take vertical load applied in both shear and compression to give maximum isolation from vibrating machinery. Suitable for use in a wide variety of applications including pumps, compressors, centrifugal fans, and blowers.
| Product Name: | Anti-vibration mount |
| Specifications: | 100~2000kg |
| Elastic component: | rubber |
| Metal parts: | white galvanized steel sheet UN-ISO 2081 |
| Applicable environment: | -40 ° C ~ 120 ° C |
Application:
A gasoline engine, motor, generator, compressor, engine, electric pump, air conditioning.
Characteristics:
Low dynamic coefficient, good anti-vibration effect, small size, low height, stable performance, easy and convenient installation, can be directly placed between the isolated unit and the ground, generally without anchor bolts, no concrete foundation, short construction period, Low investment is the ideal product for domestic power machinery to implement no basic anti-vibration
| KG | A(mm) | B(mm) | C(mm) | D(mm) | E(mm) | F(mm) |
| 100KGS | 70 | 34 | M12 | 75 | 100 | 130 |
| 200KGS | 95 | 43 | M12,M14,M16 | 100 | 120 | 153 |
| 300KGS | 100 | 43 | M12,M14,M16 | 100 | 120 | 153 |
| 400KGS | 100 | 44 | M12,M14,M16 | 108 | 143 | 178 |
| 500KGS | 100 | 44 | M12,M14,M16 | 108 | 143 | 178 |
| 600KGS | 122 | 52 | M14, M16 | 125 | 158 | 190 |
| 800KGS | 150 | 56 | M18, M20 | 151 | 182 | 216 |
| 1000KGS | 150 | 56 | M18, M20 | 151 | 182 | 216 |
| 2000KGS | 151 | 58 | M20 | 143 | 130 | 167 |
| Thick and smooth steel Adopting the stainless steel in high hardness to ensure the strong enough for the machinery. The rubber inside is oil-prevent and anti-shock. Can apply for the outside using and anti-rusty | |
| A perfect match between metal and rubber The smooth surface treatment and the high accuracy screw and the perfect match between metal & rubber can prevent vibration, shock, and noise of the machine and equipment to the biggest degree |
| Complete product model Metal rubber shock absorbers are available in a full range of models | |
| Multiple installation methods Metal rubber dampers are available in a variety of mounting styles, including flat, side, and side mounts. The transverse stiffness is higher than the longitudinal stiffness, and the lateral stability is good when placed flat. |
Production line:
Guarantee:
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.
Our service:
1. Directly factory sale
2. Quick response to 2-8hours, response rates over 92%
3. 24 hours phone call is available, feel free to contact us.
4. All goods produced by ourselves, we provide one-stop services from designing, printing to processing. Customers can provide the design according to your request and the samples making, also we can advise how to make the products according to customers' target prices.
FAQ:
1. Q: What’s the MOQ?
A: We accept one piece.
2. Q: Are you a factory or trading company?
A: We are a manufacturer.
3. Q: Can you accept using our logo?
A: Yes, we can do OEM for you.
4. Q: What’s the warranty period?
A: 1 year.
5. Q: What are the terms of payment?
A: T/T. 30% deposit and 70% against the BL copy or 100% LC at sight.
